TCK6050
CNC Slant Bed Lathe
- Max. Turning Length
550mm
- Max. Turning Diameter
500mm
- X-axis Travel Distance
260mm
- Z-axis Travel Distance
630mm
Machine Introduction
Introduction
The TCK6050 slant bed CNC lathe is the medium-size standard turning model in this product range. It is a general turning model to compare between the small TCK50 and large TCK70 size classes.
Base selection on the diameter and length to be machined, including the chucking allowance and tool access. The TCK6050D provides a precision-focused comparison, while the TCK6050Y belongs to the turn-mill range. Share a drawing and the planned blank form to discuss which model matches your turning process.
Key Features
*Spindle end type A2-6, spindle hole diameter 65 mm, max bar diameter 50 mm, spindle speed range 50~4000 r/min, max output torque 182 Nm
*X-axis travel 280 mm, Z-axis travel 620 mm, X/Z fast moving speed 15/15 m/min
*Machine dimensions 3240×1940×1965 mm, machine weight 3800 kg
Machine Details
Technical Parameters
| Speicifications | TCK6050-500 |
|---|---|
| Max. swing over bed(mm) | 560 |
| Max. turning length(mm) | 550 |
| Max. turning diameter(mm) | 500 |
| Max. swing over cross slide(mm) | 320 |
| Standard turning diameter(mm) | 280 |
| Spindle nose type / code | A2-6 |
| Spindle bore diameter(mm) | 65 |
| Max. bar capacity(mm) | 50 |
| Spindle motor output power(kW) | 11/15 |
| X-axis rapid traverse(m/min) | 15 |
| Z-axis rapid traverse(m/min) | 15 |
| X-axis travel(mm) | 260 |
| Z-axis travel(mm) | 630 |
| Tailstock travel(mm) | 450 |
| Tailstock quill stroke(mm) | 100 |
| Approx. gross weight(KG) | 3800 |
| Machine dimensions(mm) | 3238L*1925W*1966H |
Related Products
TCK50 CNC Slant Bed Lathe
TCK70 CNC Slant Bed Lathe
TCK6350B CNC Slant Bed Lathe
TCK6050D CNC Slant Bed Lathe
Frequently Asked Questions
Q: What separates the TCK6050 from the TCK6050D?
A: The TCK6050 is the standard model and the TCK6050D is precision-focused in this product range. Compare documented accuracy and configuration details.
Q: Should I choose a lathe by swing over bed alone?
A: No. Maximum turning diameter, tooling clearance and chucking arrangements can limit the actual part size.
Q: What blank information should I provide?
A: Specify whether the job starts from bar, a cut blank, a casting or a forging, and include its dimensions and material.
